| Specification | Details |
|---|---|
| Loss Tangent | 0.002 |
| Breakdown Voltage | 2.5 kV AC (Between Terminals and Case) |
| Lead Spacing | Not Applicable (Stud/Threaded Terminal) |
| Insulation Resistance | >5000 MΩ |
| Frequency | 50/60 Hz |
| Current | Rated Current up to 39.3A |
| Insulation Voltage | 3000V AC |
| Product Type | Heavy Electrical Capacitor |
| Material | Metal, Porcelain, Insulating Film |
| Capacitance | 30 kVAR |
| Shell | Metal Enclosure |
| Operating Temperature | -40°C to +70°C |
| Rated Voltage | 440V AC |
| Ripple | Suitable for Moderate Ripple Current |
| Capacitance Tolerance | ±5% |
| Temperature Range | -40°C to +70°C |
| Shape | Rectangular |
| Terminal | Stud/Threaded Terminal |
| Application | Power Factor Correction, Electrical Distribution Panels, Industrial Power Systems |
| Size | Approx. 300 mm x 120 mm x 90 mm |
| Color | Silver/Grey |
| Mounting Type | Panel Mounted |
| Humidity | Up to 95% RH (Non-Condensing) |
| Dielectric | Polypropylene Film |
| Maximum Altitude | 2000 m above sea level |
| Discharge Resistor | Built-in |
| Weight | Approx. 3.2 kg |
| Self-Healing Properties | Yes |
| Protection Class | IP20 |
| Standards | IS 13585, IEC 60831-1/2 |
| Trade Information | Details |
|---|---|
| Minimum Order Quantity | 1 Piece |
| Supply Ability | 100 Pieces Per Month |
| Delivery Time | 1 Week |
| Sample Policy | Contact us for information regarding our sample policy |
| Packaging Details | Depend on product, wooden box/Carton box |
| Main Domestic Market | All India |
Superior Energy Efficiency and Safety
Engineered with a polypropylene film dielectric and a built-in discharge resistor, this capacitor provides advanced performance and secure operation. Its metal enclosure and self-healing properties enhance durability and minimize risks, making it an ideal choice for demanding industrial settings.
Compliance with Industry Standards
This heavy electrical capacitor meets IS 13585 and IEC 60831-1/2 standards, ensuring reliability and quality in power factor correction. Its insulation and breakdown voltages guarantee robust protection, while the IP20 rating secures safe panel mounting and operation.
Designed for Tough Environments
Adapted for harsh conditions, it withstands temperature ranges from -40C to +70C and humidity up to 95% RH (non-condensing). Suitable for installation up to 2000 meters above sea level, its rugged construction ensures longevity in both industrial and commercial facilities.
FAQs of Heavy Electrical Capacitor:
Q: How is the Heavy Electrical Capacitor installed in electrical systems?
A: The capacitor is panel mounted using its rectangular metal enclosure and stud/threaded terminals, making it easy to integrate with electrical distribution panels and industrial power systems.
Q: What protections does the capacitor offer during operation?
A: It includes a built-in discharge resistor for safety, self-healing dielectric properties, and conforms to IP20 for protection against accidental contact, minimizing operational hazards.
Q: When should this capacitor be used in power factor correction?
A: This capacitor is designed for use in power factor correction whenever efficient energy usage and voltage stability are needed in industrial and commercial power systems.
Q: Where can the capacitor be effectively utilized?
A: It is ideal for deployment in electrical distribution panels, industrial power systems, and environments with moderate ripple current, operating efficiently at altitudes up to 2000 meters.
Q: What is the process for ensuring the capacitors compatibility with the system?
A: Check system specifications for rated voltage (440V AC), capacitance (30 kVAR), frequency (50/60 Hz), and ensure panel mounting capabilities align with the capacitors size and terminal type.
Q: How does the self-healing property of the capacitor benefit users?
A: Self-healing properties allow the capacitor to recover from minor electrical faults, enhancing operational reliability and extending service life, which reduces maintenance and downtime.
Q: What are the primary materials used in this capacitor?
A: The capacitor consists of metal, porcelain, and insulating film, ensuring high durability, electrical insulation, and robust performance under diverse environmental conditions.
